Mark Williams - 35105 - Anti Roll Bar Assembly 3in Dia x 1-1/4 Spline

Heavy Duty Anti-Roll Bar assembly features 3″ diameter main tube and splined 7075 aluminum arms clevis design to accept 3/8″ rod ends.

The spherical bearing assembly allows for bending without binding. At the same time, the 3″ diameter tube is 88.7% stiffer than a standard 1.25″ anti-roll assembly which translates to one degree of twist for every 8.87 degrees in a standard setup.

Standard arm length is 5″ and max center to center width of arms is 22.25″. This kit comes with an extra long 3″ x 16.5″ main tube which can be cut to accommodate most chassis widths.

The unit features splined ends with 1-1/4" serration for secure attachment. 16" of 3" 4130 tube which will give you a max width of 21.688" center of arm to center of arm, with 35103 bearings, and 6" arms (p/n 35102).

If custom width is needed, please call for availability. Linkage kit (part number 35110) sold separately.
