Cold Case Radiators - GMA546ASK - 68-77 A-Body LS SWAP Aluminum Radiator And Dual 14 Inch Fans

1968-1977 GM A-Body with LS Swap Aluminum Performance Dual Flow Radiator and 14 Inch fan kit. Meant to be used with an external trans cooler.

When you need the biggest and best, look no further than the Cold Case Super Duty Line. All Super Duty kits include 2 row radiators with 1.25 Inch tubes, aluminum fan shroud and dual 14 Inch fans, flowing at 2200cfm per fan! For extreme horsepower applications OR if you just want the best of the best...

These COLD-CASE radiators are Tig welded 100 percent aluminum and absolutely beautiful. Don't buy a 3 or 4 row aluminum radiator! It doesn't cool as good as these oversize 2 row models.

These radiators are original appearing and have the correct stamping. Once painted, you'd be hard pressed to find a difference over an original versus a COLD-CASE.

• 100 percent TIG welded
• Fan Diameter 12 Inch
• All Aluminum
• (2) 1.25 inch Tubes
• Polished OE style tanks
• 16 fins per inch
• Corrugated fins that give more surface area and more thermal transfer
• Pressure tested
• Dual Flow Design
• Direct fitment for 68-77 A-Body LS Swaps

Old Part Number: RPE546AK
Radiator Specs

• Core Height 18.4 inch
• Core Width 28.5 inch
• Overall Height 18.82 inch
• Overall Width 34.21 inch
• Overall Thickness 3 inch
• Upper Hose 1.25 inch
• Lower Hose 1.5 inch
• Tubes (2) 1.25 inch Tubes

Leverantörens artikelnummer: GMA546ASK

1968 1968 Chevrolet Chevelle 300
1968 1972 Chevrolet El Camino
1968 1972 Chevrolet Chevelle SS
1968 1972 Chevrolet El Camino SS
1968 1969 Pontiac Tempest Safari
1968 1968 Oldsmobile Cutlass S
1968 1972 Chevrolet Chevelle Nomad
1968 1972 Chevrolet Chevelle Malibu
1968 1972 Buick Skylark Custom
1968 1972 Chevrolet El Camino Custom
1968 1969 Chevrolet Chevelle 300 Deluxe
1968 1972 Chevrolet Chevelle Concours
1968 1969 Pontiac Tempest Custom
1968 1972 Oldsmobile Cutlass
1968 1971 Oldsmobile 442
1968 1970 Pontiac Tempest
1968 1972 Pontiac Grand Prix
1968 1972 Pontiac LeMans
1968 1972 Pontiac GTO
1968 1972 Buick Skylark
1968 1968 Chevrolet Chevelle
1969 1972 Chevrolet Chevelle Greenbrier
1969 1972 Chevrolet Chevelle Concours Estate
1969 1970 Pontiac LeMans Safari
1970 1970 Pontiac Tempest GT
1970 1972 Chevrolet Chevelle
1970 1972 Pontiac LeMans Sport
1970 1970 Buick Skylark 350
1970 1971 Pontiac GTO The Judge
1971 1972 Oldsmobile Cutlass S
1971 1971 Pontiac LeMans T37
1972 1972 Pontiac LeMans Luxury
1972 1972 Oldsmobile Cutlass Cruiser
1972 1972 Buick Skylark 350
